SPECIFICATIONS |
MODEL SP2800 |
| GENERATOR |
Type |
Brushless single phase alternator |
| Frequency Hz |
50/ 60 |
| Speed rpm |
3000 |
3600 |
| Max output Kw |
2.4 |
2.8 |
| Cont output Kw |
2.2 |
2.5 |
| Voltage V |
120 / 220 / 240 |
| DC output |
12V – 8.3 amp |
| Power Factor |
1.0 |
| ENGINE |
Model |
Kapa F210 |
| Type |
Single cylinder, 4 stroke vertical, air cooled, direct injection diesel engine |
| Bore x Stroke mm ( Inch ) |
70 x 55 mm ( 2.75 x 2.16 inch ) |
| Displacement cc |
211 |
| Recommended fuel |
Diesel |
| Fuel tank capacity Gal ( Lit ) |
3.3 ( 12.5 ) |
| Engine speed rpm |
3000 |
3600 |
| Max output hp |
4.2 |
4.7 |
| Cot output hp |
3.8 |
4.2 |
| Starting system |
Electric and hand starter |
STANDARD
FEATURES |
Oil alert |
yes |
| Fuel gauge |
yes |
| Ac voltmeter |
yes |
| Ac circuit breaker |
yes |
| Electric starter |
yes |
| DC circuit breaker |
yes |
| Battery 12V |
yes |
| Handle |
yes |
| Wheels |
yes |
| SET |
Cont working time |
8 – 10 Hours |
| Noise Level @ 7 meters ( 22.9 feet ) |
75 dB ( A ) |
77 dB ( A ) |
| Packing dimension L x W x H inch
( mm ) |
24.8 x 17.92 x 24.40 ( 630 x 455 x 620 ) |
| Net weight Lb ( kg ) |
146 ( 66 ) |
| Gross weight Lb ( kg ) |
155 ( 70 ) |
